BEP_PCB Temperatures Check
Summary
| Date start | 2025:111:00:38:00.016 |
| Date stop | 2025:118:00:24:12.316 |
| Model status | NOT OK |
| Load directory | /data/acis/LoadReviews/2025/APR2125/ofls |
| Run time | Thu Apr 17 13:42:37 2025 by acisdude |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
TMP_BEP_PCB Upper Limit Violations
| Date start | Date stop | Duration (ks) | Max Temperature / Limit |
|---|---|---|---|
| 2025:111:21:33:10.816 | 2025:111:23:38:54.816 | 7.54 | 44.51 / 42.00 |
No TMP_BEP_PCB Lower Limit Violations
BEP_PCB Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where TMP_BEP_PCB >= 20.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| tmp_bep_pcb | -11.75 | -9.77 | -7.08 | -2.65 | 0.73 | 2.48 | 3.65 |
| pitch | -5.703 | -0.505 | -0.004 | 0.000 | 0.004 | 0.585 | 5.567 |
| tscpos | -1 | -1 | -1 | 0 | 0 | 1 | 1 |
| roll | -1.477 | -0.108 | -0.008 | 0.000 | 0.009 | 0.168 | 1.369 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| TMP_BEP_PCB | 1 | -11.75 | 2.00 |
| TMP_BEP_PCB | 50 | -2.65 | 1.00 |
| TMP_BEP_PCB | 99 | 3.65 | 2.00 |
| PITCH | 1 | -5.703 | 3.00 |
| PITCH | 99 | 5.567 | 3.00 |
TMP_BEP_PCB
Note: TMP_BEP_PCB residual histograms include only points where TMP_BEP_PCB >= 20.0 C in blue and points where TMP_BEP_PCB <= 20.0 C in red.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
