BEP_PCB Temperatures Check
Summary
| Date start | 2025:146:01:40:21.716 |
| Date stop | 2025:152:23:54:14.516 |
| Model status | OK |
| Load directory | /data/acis/LoadReviews/2025/MAY2625/ofls |
| Run time | Fri May 23 11:22:06 2025 by acisdude |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
No TMP_BEP_PCB Upper Limit Violations
No TMP_BEP_PCB Lower Limit Violations
BEP_PCB Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where TMP_BEP_PCB >= 20.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| tmp_bep_pcb | -9.80 | -7.30 | -4.76 | -0.62 | 1.63 | 3.53 | 5.51 |
| pitch | -5.217 | -0.249 | -0.004 | 0.000 | 0.004 | 0.440 | 5.469 |
| tscpos | -1 | -1 | -1 | 0 | 0 | 0 | 1 |
| roll | -1.502 | -0.096 | -0.005 | 0.000 | 0.005 | 0.122 | 1.401 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| TMP_BEP_PCB | 1 | -9.8 | 2.00 |
| TMP_BEP_PCB | 99 | 5.51 | 2.00 |
| PITCH | 1 | -5.217 | 3.00 |
| PITCH | 99 | 5.469 | 3.00 |
TMP_BEP_PCB
Note: TMP_BEP_PCB residual histograms include only points where TMP_BEP_PCB >= 20.0 C in blue and points where TMP_BEP_PCB <= 20.0 C in red.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
