BEP_PCB Temperatures Check
Summary
| Date start | 2026:277:13:10:00.016 |
| Date stop | 2026:284:19:12:22.016 |
| Model status | NOT OK |
| Load directory | /data/acis/LoadReviews/2026/OCT0526/oflsa |
| Run time | Thu Oct 1 08:51:18 2026 by acisdude |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
TMP_BEP_PCB Upper Limit Violations
| Date start | Date stop | Duration (ks) | Max Temperature / Limit |
|---|---|---|---|
| 2026:280:03:01:10.816 | 2026:280:05:17:50.816 | 8.20 | 51.02 / 42.00 |
| 2026:282:02:56:38.816 | 2026:282:03:45:50.816 | 2.95 | 43.45 / 42.00 |
| 2026:282:18:53:18.816 | 2026:282:21:15:26.816 | 8.53 | 49.87 / 42.00 |
| 2026:283:12:55:42.816 | 2026:283:13:54:01.887 | 3.50 | 44.20 / 42.00 |
| 2026:283:23:24:22.816 | 2026:284:00:18:40.975 | 3.26 | 44.08 / 42.00 |
No TMP_BEP_PCB Lower Limit Violations
BEP_PCB Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where TMP_BEP_PCB >= 20.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| tmp_bep_pcb | -11.76 | -8.87 | -6.32 | -2.24 | 1.59 | 3.10 | 4.08 |
| pitch | -12.048 | -1.672 | -0.004 | -0.000 | 0.004 | 1.769 | 12.896 |
| tscpos | -303 | -1 | -1 | 0 | 0 | 1 | 1 |
| roll | -2.106 | -0.273 | -0.010 | 0.000 | 0.010 | 0.250 | 1.801 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| TMP_BEP_PCB | 1 | -11.76 | 2.00 |
| TMP_BEP_PCB | 50 | -2.24 | 1.00 |
| TMP_BEP_PCB | 99 | 4.08 | 2.00 |
| PITCH | 1 | -12.048 | 3.00 |
| PITCH | 99 | 12.896 | 3.00 |
| TSCPOS | 1 | -303.0 | 2.50 |
TMP_BEP_PCB
Note: TMP_BEP_PCB residual histograms include only points where TMP_BEP_PCB >= 20.0 C in blue and points where TMP_BEP_PCB <= 20.0 C in red.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
