DEA Temperatures Check

Summary

Date start 2026:012:00:51:56.516
Date stop 2026:019:00:52:29.616
Model status OK
Load directory /data/acis/LoadReviews/2026/JAN1226/oflsa
Run time Thu Jan 8 08:39:14 2026 by acisdude
Run log run.dat
Temperatures temperatures.dat
States states.dat

No 1DEAMZT Upper Limit Violations

1deamzt.png pow_sim.png roll.png

DEA Model Validation

MSID quantiles

Note: Quantiles are calculated using only points where 1DEAMZT >= 20.0 C.

MSID 1% 5% 16% 50% 84% 95% 99%
1deamzt -1.33 -0.83 -0.47 0.33 1.48 1.99 2.76
pitch -11.683 -0.818 -0.004 -0.000 0.004 0.584 11.250
tscpos -1 -1 -1 0 0 0 0
roll -1.743 -0.205 -0.007 -0.000 0.007 0.165 2.005

Validation Violations

MSID Quantile Value Limit
1DEAMZT 99 2.76 2.00
PITCH 1 -11.683 3.00
PITCH 99 11.25 3.00

1DEAMZT

Note: 1DEAMZT residual histograms include only points where 1DEAMZT >= 20.0 C.

1deamzt_valid.png 1deamzt_valid_hist.png

PITCH

pitch_valid.png pitch_valid_hist.png

TSCPOS

tscpos_valid.png tscpos_valid_hist.png

ROLL

roll_valid.png roll_valid_hist.png

ACIS CCD/FEP Count
