DEA Temperatures Check
Summary
| Date start | 2026:200:20:45:00.016 |
| Date stop | 2026:207:21:54:34.216 |
| Model status | OK |
| Load directory | /data/acis/LoadReviews/2026/JUL2026/oflsa |
| Run time | Wed Jul 15 08:18:42 2026 by acisdude |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
No 1DEAMZT Upper Limit Violations
DEA Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where 1DEAMZT >= 20.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| 1deamzt | -2.15 | -1.21 | -0.47 | 0.64 | 1.54 | 2.07 | 3.03 |
| pitch | -8.799 | -0.443 | -0.004 | -0.000 | 0.004 | 0.286 | 10.598 |
| tscpos | -1 | -1 | -1 | 0 | 0 | 1 | 1 |
| roll | -1.953 | -0.105 | -0.007 | 0.000 | 0.006 | 0.099 | 1.870 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| 1DEAMZT | 1 | -2.15 | 2.00 |
| 1DEAMZT | 99 | 3.03 | 2.00 |
| PITCH | 1 | -8.799 | 3.00 |
| PITCH | 99 | 10.598 | 3.00 |
1DEAMZT
Note: 1DEAMZT residual histograms include only points where 1DEAMZT >= 20.0 C.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
