DEA temperatures check
Summary
| Date start | 2020:148:00:57:00.000 |
| Date stop | 2020:149:01:00:00.000 |
| Model status | OK (Planning Limit = 36.5 C) |
| Load directory | /data/acis/LoadReviews/2020/MAY2620/ofls |
| Run time | Tue May 26 21:20:54 2020 by acisdude |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
No 1DEAMZT Hot Violations
DEA Model Validation
MSID quantiles
Note: DEA quantiles are calculated using only points where 1DEAMZT > 20.0 degC.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| 1DEAMZT | -2.09 | -1.87 | -1.60 | -1.06 | -0.25 | 0.60 | 1.55 |
| PITCH | -5.031 | -0.006 | -0.001 | -0.000 | 0.001 | 0.005 | 3.442 |
| TSCPOS | -1 | -1 | -1 | -1 | 0 | 1 | 1 |
| ROLL | -0.561 | -0.012 | -0.003 | 0.000 | 0.003 | 0.013 | 0.642 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| 1DEAMZT | 1 | -2.09 | 2.00 |
| 1DEAMZT | 50 | -1.06 | 1.00 |
| PITCH | 1 | -5.031 | 3.00 |
| PITCH | 99 | 3.442 | 3.00 |
1DEAMZT
Note: DEA residual histograms include only points where 1DEAMZT >= 20.0 degC.
PITCH
TSCPOS
ROLL
CCD/FEP Count
