DEA Temperatures Check

Summary

Date start 2025:295:21:30:00.016
Date stop 2025:299:22:52:08.316
Model status OK
Load directory /data/acis/LoadReviews/2025/OCT2225/oflsa
Run time Mon Oct 20 22:03:13 2025 by acisdude
Run log run.dat
Temperatures temperatures.dat
States states.dat

No 1DEAMZT Upper Limit Violations

1deamzt.png pow_sim.png roll.png

DEA Model Validation

MSID quantiles

Note: Quantiles are calculated using only points where 1DEAMZT >= 20.0 C.

MSID 1% 5% 16% 50% 84% 95% 99%
1deamzt -2.08 -1.31 -0.83 -0.04 0.95 1.39 2.12
pitch -10.614 -1.241 -0.004 -0.000 0.004 0.821 12.240
tscpos -1 -1 -1 0 0 0 1
roll -2.049 -0.104 -0.007 0.000 0.009 0.284 2.326

Validation Violations

MSID Quantile Value Limit
1DEAMZT 1 -2.08 2.00
1DEAMZT 99 2.12 2.00
PITCH 1 -10.614 3.00
PITCH 99 12.24 3.00

1DEAMZT

Note: 1DEAMZT residual histograms include only points where 1DEAMZT >= 20.0 C.

1deamzt_valid.png 1deamzt_valid_hist.png

PITCH

pitch_valid.png pitch_valid_hist.png

TSCPOS

tscpos_valid.png tscpos_valid_hist.png

ROLL

roll_valid.png roll_valid_hist.png

ACIS CCD/FEP Count
