DPAMYT Temperatures Check
Summary
| Date start | 2025:166:13:51:00.016 |
| Date stop | 2025:174:00:04:24.716 |
| Model status | OK |
| Load directory | /data/acis/LoadReviews/2025/JUN1625/ofls |
| Run time | Wed Jun 11 12:15:30 2025 by acisdude |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
No 1DPAMYT Upper Limit Violations
DPAMYT Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where 1DPAMYT >= 20.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| 1dpamyt | -3.77 | -1.61 | -0.10 | 0.82 | 1.49 | 1.85 | 2.35 |
| pitch | -5.124 | -0.233 | -0.004 | 0.000 | 0.004 | 0.311 | 5.162 |
| tscpos | -1 | -1 | -1 | 0 | 0 | 0 | 1 |
| roll | -1.307 | -0.118 | -0.005 | -0.000 | 0.005 | 0.080 | 1.325 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| 1DPAMYT | 1 | -3.77 | 2.00 |
| 1DPAMYT | 99 | 2.35 | 2.00 |
| PITCH | 1 | -5.124 | 3.00 |
| PITCH | 99 | 5.162 | 3.00 |
1DPAMYT
Note: 1DPAMYT residual histograms include only points where 1DPAMYT >= 20.0 C.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
