DPAMYT Temperatures Check
Summary
| Date start | 2025:131:21:12:39.216 |
| Date stop | 2025:139:00:00:00.816 |
| Model status | OK |
| Load directory | /data/acis/LoadReviews/2025/MAY1225/ofls |
| Run time | Wed May 7 09:44:11 2025 by acisdude |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
No 1DPAMYT Upper Limit Violations
DPAMYT Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where 1DPAMYT >= 20.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| 1dpamyt | -2.18 | -1.16 | -0.44 | 0.68 | 1.62 | 2.11 | 3.36 |
| pitch | -6.454 | -0.384 | -0.004 | 0.000 | 0.004 | 0.541 | 5.426 |
| tscpos | -1 | -1 | -1 | -1 | 0 | 1 | 1 |
| roll | -1.576 | -0.104 | -0.004 | 0.000 | 0.005 | 0.131 | 1.195 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| 1DPAMYT | 1 | -2.18 | 2.00 |
| 1DPAMYT | 99 | 3.36 | 2.00 |
| PITCH | 1 | -6.454 | 3.00 |
| PITCH | 99 | 5.426 | 3.00 |
1DPAMYT
Note: 1DPAMYT residual histograms include only points where 1DPAMYT >= 20.0 C.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
