DPAMYT Temperatures Check
Summary
| Date start | 2025:327:21:03:00.016 |
| Date stop | 2025:335:01:22:35.216 |
| Model status | OK |
| Load directory | /data/acis/LoadReviews/2025/NOV2425/oflsa |
| Run time | Wed Nov 19 21:04:49 2025 by acisdude |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
No 1DPAMYT Upper Limit Violations
DPAMYT Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where 1DPAMYT >= 20.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| 1dpamyt | -1.00 | -0.64 | -0.19 | 0.64 | 1.22 | 1.74 | 3.57 |
| pitch | -12.655 | -1.681 | -0.004 | 0.000 | 0.004 | 1.399 | 12.292 |
| tscpos | -1 | -1 | -1 | 0 | 0 | 0 | 1 |
| roll | -2.475 | -0.215 | -0.007 | -0.000 | 0.007 | 0.273 | 2.424 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| 1DPAMYT | 99 | 3.57 | 2.00 |
| PITCH | 1 | -12.655 | 3.00 |
| PITCH | 99 | 12.292 | 3.00 |
1DPAMYT
Note: 1DPAMYT residual histograms include only points where 1DPAMYT >= 20.0 C.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
