DPA Temperatures Check
Summary
| Date start | 2026:235:21:56:21.316 |
| Date stop | 2026:242:22:06:33.816 |
| Model status | NOT OK |
| Load directory | /data/acis/LoadReviews/2026/AUG2426/oflsa |
| Run time | Wed Aug 19 13:20:11 2026 by acisdude |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
No 1DPAMZT Upper Limit Violations
1DPAMZT Lower Limit Violations
| Date start | Date stop | Duration (ks) | Min Temperature / Limit |
|---|---|---|---|
| 2026:237:15:00:43.000 | 2026:237:15:00:45.251 | 0.00 | 12.69 / 13.00 |
| 2026:237:16:27:49.933 | 2026:237:16:27:57.800 | 0.01 | 11.17 / 13.00 |
| 2026:241:13:46:57.009 | 2026:241:13:47:10.816 | 0.01 | 10.33 / 13.00 |
| 2026:242:17:17:44.837 | 2026:242:17:18:06.816 | 0.02 | 10.88 / 13.00 |
DPA Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where 1DPAMZT >= 20.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| 1dpamzt | -1.94 | -1.10 | -0.63 | 0.05 | 0.64 | 1.32 | 1.77 |
| pitch | -10.114 | -1.018 | -0.004 | -0.000 | 0.004 | 0.970 | 10.524 |
| tscpos | -1 | -1 | -1 | -1 | 0 | 1 | 1 |
| roll | -1.786 | -0.196 | -0.007 | 0.000 | 0.008 | 0.294 | 1.955 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| PITCH | 1 | -10.114 | 3.00 |
| PITCH | 99 | 10.524 | 3.00 |
1DPAMZT
Note: 1DPAMZT residual histograms include only points where 1DPAMZT >= 20.0 C.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
