DPA Temperatures Check
Summary
| Date start | 2025:003:03:20:59.016 |
| Date stop | 2025:013:04:44:00.016 |
| Model status | NOT OK |
| Load directory | /data/acis/LoadReviews/2025/JAN0325/ofls |
| Run time | Wed Jan 1 21:07:10 2025 by acisdude |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
No 1DPAMZT Upper Limit Violations
1DPAMZT Lower Limit Violations
| Date start | Date stop | Duration (ks) | Min Temperature / Limit |
|---|---|---|---|
| 2025:006:06:23:37.865 | 2025:006:06:23:50.308 | 0.01 | 11.96 / 13.00 |
| 2025:009:18:45:14.984 | 2025:009:18:45:18.816 | 0.00 | 12.29 / 13.00 |
| 2025:011:10:18:19.710 | 2025:011:10:18:43.510 | 0.02 | 11.32 / 13.00 |
DPA Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where 1DPAMZT >= 20.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| 1dpamzt | -2.30 | -1.74 | -1.03 | -0.23 | 0.58 | 1.13 | 1.91 |
| pitch | -6.275 | -0.716 | -0.004 | 0.000 | 0.004 | 0.741 | 6.515 |
| tscpos | -1 | -1 | -1 | 0 | 0 | 0 | 1 |
| roll | -1.106 | -0.149 | -0.008 | 0.000 | 0.008 | 0.197 | 1.320 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| 1DPAMZT | 1 | -2.3 | 2.00 |
| PITCH | 1 | -6.275 | 3.00 |
| PITCH | 99 | 6.515 | 3.00 |
1DPAMZT
Note: 1DPAMZT residual histograms include only points where 1DPAMZT >= 20.0 C.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
