DPA Temperatures Check
Summary
| Date start | 2026:012:00:51:56.516 |
| Date stop | 2026:019:00:52:29.616 |
| Model status | NOT OK |
| Load directory | /data/acis/LoadReviews/2026/JAN1226/oflsa |
| Run time | Thu Jan 8 08:38:19 2026 by acisdude |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
No 1DPAMZT Upper Limit Violations
1DPAMZT Lower Limit Violations
| Date start | Date stop | Duration (ks) | Min Temperature / Limit |
|---|---|---|---|
| 2026:014:09:03:50.181 | 2026:014:09:04:13.335 | 0.02 | 10.11 / 13.00 |
| 2026:015:13:29:01.479 | 2026:015:13:29:10.816 | 0.01 | 10.83 / 13.00 |
| 2026:018:20:26:29.632 | 2026:018:20:26:36.445 | 0.01 | 12.29 / 13.00 |
DPA Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where 1DPAMZT >= 20.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| 1dpamzt | -2.16 | -1.95 | -0.99 | 0.09 | 1.05 | 1.84 | 2.38 |
| pitch | -11.683 | -0.818 | -0.004 | -0.000 | 0.004 | 0.584 | 11.250 |
| tscpos | -1 | -1 | -1 | 0 | 0 | 0 | 0 |
| roll | -1.743 | -0.205 | -0.007 | -0.000 | 0.007 | 0.165 | 2.005 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| 1DPAMZT | 1 | -2.16 | 2.00 |
| 1DPAMZT | 99 | 2.38 | 2.00 |
| PITCH | 1 | -11.683 | 3.00 |
| PITCH | 99 | 11.25 | 3.00 |
1DPAMZT
Note: 1DPAMZT residual histograms include only points where 1DPAMZT >= 20.0 C.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
