DPA Temperatures Check
Summary
| Date start | 2026:025:19:05:18.516 |
| Date stop | 2026:032:23:33:17.516 |
| Model status | NOT OK |
| Load directory | /data/acis/LoadReviews/2026/JAN2626/oflsa |
| Run time | Thu Jan 22 12:56:23 2026 by acisdude |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
No 1DPAMZT Upper Limit Violations
1DPAMZT Lower Limit Violations
| Date start | Date stop | Duration (ks) | Min Temperature / Limit |
|---|---|---|---|
| 2026:026:19:19:44.765 | 2026:026:19:19:52.481 | 0.01 | 9.78 / 13.00 |
| 2026:031:23:32:30.324 | 2026:031:23:32:30.816 | 0.00 | 9.82 / 13.00 |
DPA Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where 1DPAMZT >= 20.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| 1dpamzt | -2.39 | -1.53 | -0.86 | 0.08 | 0.94 | 1.49 | 2.22 |
| pitch | -11.845 | -0.587 | -0.004 | 0.000 | 0.004 | 0.706 | 11.217 |
| tscpos | -1 | -1 | -1 | 0 | 0 | 0 | 1 |
| roll | -2.121 | -0.234 | -0.009 | -0.000 | 0.006 | 0.172 | 1.759 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| 1DPAMZT | 1 | -2.39 | 2.00 |
| 1DPAMZT | 99 | 2.22 | 2.00 |
| PITCH | 1 | -11.845 | 3.00 |
| PITCH | 99 | 11.217 | 3.00 |
1DPAMZT
Note: 1DPAMZT residual histograms include only points where 1DPAMZT >= 20.0 C.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
