DPA Temperatures Check
Summary
| Date start | 2025:187:17:20:00.016 |
| Date stop | 2025:195:01:16:43.816 |
| Model status | NOT OK |
| Load directory | /data/acis/LoadReviews/2025/JUL0725/ofls |
| Run time | Thu Jul 3 10:26:07 2025 by acisdude |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
No 1DPAMZT Upper Limit Violations
1DPAMZT Lower Limit Violations
| Date start | Date stop | Duration (ks) | Min Temperature / Limit |
|---|---|---|---|
| 2025:188:03:31:00.295 | 2025:188:03:31:10.816 | 0.01 | 12.61 / 13.00 |
| 2025:189:13:13:16.895 | 2025:189:13:13:17.183 | 0.00 | 11.10 / 13.00 |
| 2025:192:01:31:00.119 | 2025:192:01:31:17.961 | 0.02 | 11.73 / 13.00 |
| 2025:194:21:52:38.803 | 2025:194:21:52:46.816 | 0.01 | 12.30 / 13.00 |
DPA Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where 1DPAMZT >= 20.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| 1dpamzt | -2.70 | -2.28 | -1.20 | -0.34 | 0.34 | 0.64 | 0.79 |
| pitch | -7.671 | -0.176 | -0.004 | -0.000 | 0.004 | 0.366 | 10.157 |
| tscpos | -1 | -1 | -1 | 0 | 0 | 0 | 1 |
| roll | -1.724 | -0.087 | -0.007 | 0.000 | 0.007 | 0.109 | 1.941 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| 1DPAMZT | 1 | -2.7 | 2.00 |
| PITCH | 1 | -7.671 | 3.00 |
| PITCH | 99 | 10.157 | 3.00 |
1DPAMZT
Note: 1DPAMZT residual histograms include only points where 1DPAMZT >= 20.0 C.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
