DPA Temperatures Check
Summary
| Date start | 2026:193:22:54:34.016 |
| Date stop | 2026:200:20:48:00.016 |
| Model status | NOT OK |
| Load directory | /data/acis/LoadReviews/2026/JUL1326/oflsa |
| Run time | Wed Jul 8 15:58:22 2026 by acisdude |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
No 1DPAMZT Upper Limit Violations
1DPAMZT Lower Limit Violations
| Date start | Date stop | Duration (ks) | Min Temperature / Limit |
|---|---|---|---|
| 2026:193:23:20:22.685 | 2026:193:23:20:38.816 | 0.02 | 11.29 / 13.00 |
| 2026:194:21:59:20.637 | 2026:194:21:59:31.032 | 0.01 | 12.82 / 13.00 |
| 2026:195:02:45:48.310 | 2026:195:02:46:06.816 | 0.02 | 11.80 / 13.00 |
| 2026:200:00:07:05.714 | 2026:200:00:07:10.816 | 0.01 | 11.12 / 13.00 |
| 2026:200:08:32:14.575 | 2026:200:08:32:23.784 | 0.01 | 12.41 / 13.00 |
DPA Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where 1DPAMZT >= 20.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| 1dpamzt | -3.31 | -2.61 | -1.89 | -0.09 | 0.50 | 0.74 | 1.06 |
| pitch | -10.563 | -0.398 | -0.004 | -0.000 | 0.004 | 0.123 | 10.807 |
| tscpos | -1 | -1 | -1 | 0 | 0 | 1 | 1 |
| roll | -1.788 | -0.074 | -0.006 | 0.000 | 0.006 | 0.072 | 1.559 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| 1DPAMZT | 1 | -3.31 | 2.00 |
| PITCH | 1 | -10.563 | 3.00 |
| PITCH | 99 | 10.807 | 3.00 |
1DPAMZT
Note: 1DPAMZT residual histograms include only points where 1DPAMZT >= 20.0 C.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
