DPA Temperatures Check
Summary
| Date start | 2025:208:21:28:00.016 |
| Date stop | 2025:216:00:58:48.416 |
| Model status | NOT OK |
| Load directory | /data/acis/LoadReviews/2025/JUL2825/ofls |
| Run time | Wed Jul 23 18:20:27 2025 by acisdude |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
No 1DPAMZT Upper Limit Violations
1DPAMZT Lower Limit Violations
| Date start | Date stop | Duration (ks) | Min Temperature / Limit |
|---|---|---|---|
| 2025:210:21:27:20.642 | 2025:210:21:27:26.816 | 0.01 | 11.65 / 13.00 |
DPA Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where 1DPAMZT >= 20.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| 1dpamzt | -1.12 | -0.67 | -0.23 | 0.27 | 0.82 | 1.15 | 1.50 |
| pitch | -8.836 | -0.403 | -0.004 | 0.000 | 0.004 | 0.467 | 9.377 |
| tscpos | -1 | -1 | -1 | 0 | 0 | 1 | 1 |
| roll | -2.050 | -0.136 | -0.007 | 0.000 | 0.007 | 0.173 | 1.773 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| PITCH | 1 | -8.836 | 3.00 |
| PITCH | 99 | 9.377 | 3.00 |
1DPAMZT
Note: 1DPAMZT residual histograms include only points where 1DPAMZT >= 20.0 C.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
