DPA Temperatures Check
Summary
| Date start | 2026:271:01:21:07.416 |
| Date stop | 2026:277:13:13:00.016 |
| Model status | NOT OK |
| Load directory | /data/acis/LoadReviews/2026/SEP2826/oflsa |
| Run time | Wed Sep 23 15:25:49 2026 by acisdude |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
No 1DPAMZT Upper Limit Violations
1DPAMZT Lower Limit Violations
| Date start | Date stop | Duration (ks) | Min Temperature / Limit |
|---|---|---|---|
| 2026:276:08:20:08.907 | 2026:276:08:20:32.449 | 0.02 | 12.33 / 13.00 |
| 2026:276:23:40:17.099 | 2026:276:23:40:38.436 | 0.02 | 9.89 / 13.00 |
| 2026:277:07:09:59.036 | 2026:277:07:10:19.413 | 0.02 | 9.74 / 13.00 |
DPA Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where 1DPAMZT >= 20.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| 1dpamzt | -2.63 | -1.40 | -0.96 | -0.04 | 0.59 | 0.95 | 1.32 |
| pitch | -12.074 | -1.526 | -0.004 | -0.000 | 0.004 | 1.416 | 12.083 |
| tscpos | -1 | -1 | -1 | 0 | 0 | 0 | 1 |
| roll | -1.937 | -0.190 | -0.009 | 0.000 | 0.010 | 0.222 | 1.702 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| 1DPAMZT | 1 | -2.63 | 2.00 |
| PITCH | 1 | -12.074 | 3.00 |
| PITCH | 99 | 12.083 | 3.00 |
1DPAMZT
Note: 1DPAMZT residual histograms include only points where 1DPAMZT >= 20.0 C.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
