FEP1_ACTEL Temperatures Check
Summary
| Date start | 2025:349:00:38:00.016 |
| Date stop | 2025:355:22:58:21.916 |
| Model status | OK |
| Load directory | /data/acis/LoadReviews/2025/DEC1525/oflsa |
| Run time | Wed Dec 10 14:40:37 2025 by acisdude |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
No TMP_FEP1_ACTEL Upper Limit Violations
No TMP_FEP1_ACTEL Lower Limit Violations
FEP1_ACTEL Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where TMP_FEP1_ACTEL >= 25.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| tmp_fep1_actel | -5.29 | -4.25 | -3.22 | -1.67 | 1.32 | 3.61 | 6.21 |
| pitch | -9.729 | -0.428 | -0.004 | -0.000 | 0.004 | 0.413 | 10.036 |
| tscpos | -1 | -1 | -1 | 0 | 0 | 1 | 1 |
| roll | -2.039 | -0.106 | -0.007 | -0.000 | 0.007 | 0.136 | 2.062 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| TMP_FEP1_ACTEL | 1 | -5.29 | 2.00 |
| TMP_FEP1_ACTEL | 50 | -1.67 | 1.00 |
| TMP_FEP1_ACTEL | 99 | 6.21 | 2.00 |
| PITCH | 1 | -9.729 | 3.00 |
| PITCH | 99 | 10.036 | 3.00 |
TMP_FEP1_ACTEL
Note: TMP_FEP1_ACTEL residual histograms include only points where TMP_FEP1_ACTEL >= 25.0 C in blue and points where TMP_FEP1_ACTEL <= 20.0 C in red.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
