FEP1_ACTEL Temperatures Check

Summary

Date start 2025:202:00:01:37.716
Date stop 2025:208:21:31:00.016
Model status NOT OK
Load directory /data/acis/LoadReviews/2025/JUL2125/ofls
Run time Thu Jul 17 13:51:57 2025 by acisdude
Run log run.dat
Temperatures temperatures.dat
States states.dat

TMP_FEP1_ACTEL Upper Limit Violations

Date start Date stop Duration (ks) Max Temperature / Limit
2025:203:12:47:34.816 2025:203:13:58:41.346 4.27 46.93 / 46.00

No TMP_FEP1_ACTEL Lower Limit Violations

tmp_fep1_actel.png pow_sim.png roll.png

FEP1_ACTEL Model Validation

MSID quantiles

Note: Quantiles are calculated using only points where TMP_FEP1_ACTEL >= 25.0 C.

MSID 1% 5% 16% 50% 84% 95% 99%
tmp_fep1_actel -3.66 -3.00 -2.32 -1.16 1.11 2.05 3.01
pitch -8.603 -0.344 -0.004 0.000 0.004 0.411 9.940
tscpos -1 -1 -1 0 0 1 1
roll -1.893 -0.132 -0.007 0.000 0.007 0.113 1.941

Validation Violations

MSID Quantile Value Limit
TMP_FEP1_ACTEL 1 -3.66 2.00
TMP_FEP1_ACTEL 50 -1.16 1.00
TMP_FEP1_ACTEL 99 3.01 2.00
PITCH 1 -8.603 3.00
PITCH 99 9.94 3.00

TMP_FEP1_ACTEL

Note: TMP_FEP1_ACTEL residual histograms include only points where TMP_FEP1_ACTEL >= 25.0 C in blue and points where TMP_FEP1_ACTEL <= 20.0 C in red.

tmp_fep1_actel_valid.png tmp_fep1_actel_valid_hist.png

PITCH

pitch_valid.png pitch_valid_hist.png

TSCPOS

tscpos_valid.png tscpos_valid_hist.png

ROLL

roll_valid.png roll_valid_hist.png

ACIS CCD/FEP Count
