FEP1_ACTEL Temperatures Check
Summary
| Date start | 2026:083:16:59:59.016 |
| Date stop | 2026:088:21:40:04.616 |
| Model status | OK |
| Load directory | /data/acis/LoadReviews/2026/MAR2426/oflsa |
| Run time | Sun Mar 22 20:47:05 2026 by acisdude |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
No TMP_FEP1_ACTEL Upper Limit Violations
No TMP_FEP1_ACTEL Lower Limit Violations
FEP1_ACTEL Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where TMP_FEP1_ACTEL >= 25.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| tmp_fep1_actel | -4.66 | -3.72 | -2.54 | -0.80 | 1.34 | 2.14 | 2.74 |
| pitch | -13.425 | -1.625 | -0.004 | 0.000 | 0.004 | 2.035 | 12.726 |
| tscpos | -1 | -1 | -1 | -1 | 0 | 0 | 1 |
| roll | -2.391 | -0.281 | -0.011 | 0.000 | 0.013 | 0.323 | 2.183 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| TMP_FEP1_ACTEL | 1 | -4.66 | 2.00 |
| TMP_FEP1_ACTEL | 99 | 2.74 | 2.00 |
| PITCH | 1 | -13.425 | 3.00 |
| PITCH | 99 | 12.726 | 3.00 |
TMP_FEP1_ACTEL
Note: TMP_FEP1_ACTEL residual histograms include only points where TMP_FEP1_ACTEL >= 25.0 C in blue and points where TMP_FEP1_ACTEL <= 20.0 C in red.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
