FEP1_ACTEL Temperatures Check
Summary
| Date start | 2025:327:21:03:00.016 |
| Date stop | 2025:335:01:22:35.216 |
| Model status | NOT OK |
| Load directory | /data/acis/LoadReviews/2025/NOV2425/oflsa |
| Run time | Wed Nov 19 21:07:56 2025 by acisdude |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
TMP_FEP1_ACTEL Upper Limit Violations
| Date start | Date stop | Duration (ks) | Max Temperature / Limit |
|---|---|---|---|
| 2025:330:11:43:50.816 | 2025:330:12:43:58.816 | 3.61 | 47.26 / 46.00 |
| 2025:332:12:12:06.816 | 2025:332:12:38:19.798 | 1.57 | 46.63 / 46.00 |
No TMP_FEP1_ACTEL Lower Limit Violations
FEP1_ACTEL Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where TMP_FEP1_ACTEL >= 25.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| tmp_fep1_actel | -7.49 | -6.21 | -4.62 | -2.80 | 0.14 | 1.80 | 2.91 |
| pitch | -12.655 | -1.630 | -0.004 | 0.000 | 0.004 | 1.399 | 12.292 |
| tscpos | -1 | -1 | -1 | 0 | 0 | 0 | 1 |
| roll | -2.475 | -0.209 | -0.007 | -0.000 | 0.007 | 0.264 | 2.420 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| TMP_FEP1_ACTEL | 1 | -7.49 | 2.00 |
| TMP_FEP1_ACTEL | 50 | -2.8 | 1.00 |
| TMP_FEP1_ACTEL | 99 | 2.91 | 2.00 |
| PITCH | 1 | -12.655 | 3.00 |
| PITCH | 99 | 12.292 | 3.00 |
TMP_FEP1_ACTEL
Note: TMP_FEP1_ACTEL residual histograms include only points where TMP_FEP1_ACTEL >= 25.0 C in blue and points where TMP_FEP1_ACTEL <= 20.0 C in red.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
