FEP1_MONG Temperatures Check
Summary
| Date start | 2026:095:21:40:32.216 |
| Date stop | 2026:103:00:29:00.016 |
| Model status | OK |
| Load directory | /data/acis/LoadReviews/2026/APR0626/oflsa |
| Run time | Thu Apr 2 10:49:33 2026 by acisdude |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
No TMP_FEP1_MONG Upper Limit Violations
No TMP_FEP1_MONG Lower Limit Violations
FEP1_MONG Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where TMP_FEP1_MONG >= 25.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| tmp_fep1_mong | -5.91 | -4.17 | -2.95 | -1.00 | 1.13 | 2.21 | 3.01 |
| pitch | -14.553 | -1.723 | -0.004 | -0.000 | 0.004 | 1.827 | 15.258 |
| tscpos | -1 | -1 | -1 | 0 | 0 | 0 | 1 |
| roll | -2.688 | -0.324 | -0.010 | -0.000 | 0.010 | 0.301 | 2.439 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| TMP_FEP1_MONG | 1 | -5.91 | 2.00 |
| TMP_FEP1_MONG | 99 | 3.01 | 2.00 |
| PITCH | 1 | -14.553 | 3.00 |
| PITCH | 99 | 15.258 | 3.00 |
TMP_FEP1_MONG
Note: TMP_FEP1_MONG residual histograms include only points where TMP_FEP1_MONG >= 25.0 C in blue and points where TMP_FEP1_MONG <= 20.0 C in red.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
