FEP1_MONG Temperatures Check
Summary
| Date start | 2025:103:21:55:07.116 |
| Date stop | 2025:111:00:41:00.016 |
| Model status | OK |
| Load directory | /data/acis/LoadReviews/2025/APR1425/ofls |
| Run time | Wed Apr 9 18:19:28 2025 by acisdude |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
No TMP_FEP1_MONG Upper Limit Violations
No TMP_FEP1_MONG Lower Limit Violations
FEP1_MONG Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where TMP_FEP1_MONG >= 25.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| tmp_fep1_mong | -5.97 | -4.22 | -2.92 | -0.88 | 0.67 | 2.09 | 3.25 |
| pitch | -7.726 | -0.496 | -0.004 | 0.000 | 0.004 | 0.608 | 7.926 |
| tscpos | -1 | -1 | -1 | 0 | 0 | 0 | 1 |
| roll | -1.858 | -0.172 | -0.008 | 0.000 | 0.009 | 0.200 | 1.912 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| TMP_FEP1_MONG | 1 | -5.97 | 2.00 |
| TMP_FEP1_MONG | 99 | 3.25 | 2.00 |
| PITCH | 1 | -7.726 | 3.00 |
| PITCH | 99 | 7.926 | 3.00 |
TMP_FEP1_MONG
Note: TMP_FEP1_MONG residual histograms include only points where TMP_FEP1_MONG >= 25.0 C in blue and points where TMP_FEP1_MONG <= 20.0 C in red.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
