FEP1_MONG Temperatures Check
Summary
| Date start | 2025:118:00:21:12.316 |
| Date stop | 2025:125:01:52:24.916 |
| Model status | OK |
| Load directory | /data/acis/LoadReviews/2025/APR2825/ofls |
| Run time | Wed Apr 23 11:36:37 2025 by acisdude |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
No TMP_FEP1_MONG Upper Limit Violations
No TMP_FEP1_MONG Lower Limit Violations
FEP1_MONG Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where TMP_FEP1_MONG >= 25.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| tmp_fep1_mong | -4.25 | -3.55 | -2.75 | -1.41 | 0.52 | 1.41 | 2.80 |
| pitch | -8.491 | -0.677 | -0.004 | 0.000 | 0.004 | 1.148 | 8.672 |
| tscpos | -1 | -1 | -1 | 0 | 0 | 1 | 1 |
| roll | -2.053 | -0.142 | -0.009 | 0.000 | 0.010 | 0.211 | 1.925 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| TMP_FEP1_MONG | 1 | -4.25 | 2.00 |
| TMP_FEP1_MONG | 50 | -1.41 | 1.00 |
| TMP_FEP1_MONG | 99 | 2.8 | 2.00 |
| PITCH | 1 | -8.491 | 3.00 |
| PITCH | 99 | 8.672 | 3.00 |
TMP_FEP1_MONG
Note: TMP_FEP1_MONG residual histograms include only points where TMP_FEP1_MONG >= 25.0 C in blue and points where TMP_FEP1_MONG <= 20.0 C in red.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
