FEP1_MONG Temperatures Check
Summary
| Date start | 2026:021:13:00:00.016 |
| Date stop | 2026:025:19:08:18.516 |
| Model status | OK |
| Load directory | /data/acis/LoadReviews/2026/JAN2126/oflsa |
| Run time | Tue Jan 20 11:41:41 2026 by acisdude |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
No TMP_FEP1_MONG Upper Limit Violations
No TMP_FEP1_MONG Lower Limit Violations
FEP1_MONG Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where TMP_FEP1_MONG >= 25.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| tmp_fep1_mong | -5.69 | -4.48 | -3.58 | -1.35 | 0.46 | 2.01 | 3.47 |
| pitch | -12.454 | -0.999 | -0.004 | -0.000 | 0.004 | 0.888 | 11.995 |
| tscpos | -1 | -1 | -1 | 0 | 0 | 0 | 1 |
| roll | -2.351 | -0.258 | -0.009 | -0.000 | 0.008 | 0.214 | 2.393 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| TMP_FEP1_MONG | 1 | -5.69 | 2.00 |
| TMP_FEP1_MONG | 50 | -1.35 | 1.00 |
| TMP_FEP1_MONG | 99 | 3.47 | 2.00 |
| PITCH | 1 | -12.454 | 3.00 |
| PITCH | 99 | 11.995 | 3.00 |
TMP_FEP1_MONG
Note: TMP_FEP1_MONG residual histograms include only points where TMP_FEP1_MONG >= 25.0 C in blue and points where TMP_FEP1_MONG <= 20.0 C in red.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
