FEP1_MONG Temperatures Check
Summary
| Date start | 2026:200:20:45:00.016 |
| Date stop | 2026:207:21:54:34.216 |
| Model status | OK |
| Load directory | /data/acis/LoadReviews/2026/JUL2026/oflsa |
| Run time | Wed Jul 15 08:21:44 2026 by acisdude |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
No TMP_FEP1_MONG Upper Limit Violations
No TMP_FEP1_MONG Lower Limit Violations
FEP1_MONG Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where TMP_FEP1_MONG >= 25.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| tmp_fep1_mong | -6.54 | -4.75 | -3.06 | -0.65 | 0.91 | 2.03 | 3.16 |
| pitch | -10.420 | -0.607 | -0.004 | -0.000 | 0.004 | 0.402 | 11.615 |
| tscpos | -1 | -1 | -1 | 0 | 0 | 1 | 1 |
| roll | -2.038 | -0.128 | -0.007 | -0.000 | 0.007 | 0.110 | 2.098 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| TMP_FEP1_MONG | 1 | -6.54 | 2.00 |
| TMP_FEP1_MONG | 99 | 3.16 | 2.00 |
| PITCH | 1 | -10.42 | 3.00 |
| PITCH | 99 | 11.615 | 3.00 |
TMP_FEP1_MONG
Note: TMP_FEP1_MONG residual histograms include only points where TMP_FEP1_MONG >= 25.0 C in blue and points where TMP_FEP1_MONG <= 20.0 C in red.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
