FEP1_MONG Temperatures Check
Summary
| Date start | 2026:081:20:41:00.016 |
| Date stop | 2026:088:21:40:04.616 |
| Model status | OK |
| Load directory | /data/acis/LoadReviews/2026/MAR2326/oflsa |
| Run time | Thu Mar 19 10:51:48 2026 by acisdude |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
No TMP_FEP1_MONG Upper Limit Violations
No TMP_FEP1_MONG Lower Limit Violations
FEP1_MONG Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where TMP_FEP1_MONG >= 25.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| tmp_fep1_mong | -6.12 | -5.30 | -3.67 | -1.13 | 0.78 | 2.17 | 2.94 |
| pitch | -14.564 | -1.750 | -0.004 | 0.000 | 0.004 | 2.346 | 14.410 |
| tscpos | -1 | -1 | -1 | -1 | 0 | 0 | 1 |
| roll | -2.757 | -0.301 | -0.011 | 0.000 | 0.013 | 0.359 | 2.513 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| TMP_FEP1_MONG | 1 | -6.12 | 2.00 |
| TMP_FEP1_MONG | 50 | -1.13 | 1.00 |
| TMP_FEP1_MONG | 99 | 2.94 | 2.00 |
| PITCH | 1 | -14.564 | 3.00 |
| PITCH | 99 | 14.41 | 3.00 |
TMP_FEP1_MONG
Note: TMP_FEP1_MONG residual histograms include only points where TMP_FEP1_MONG >= 25.0 C in blue and points where TMP_FEP1_MONG <= 20.0 C in red.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
