FEP1_MONG Temperatures Check
Summary
| Date start | 2025:138:23:57:00.816 |
| Date stop | 2025:146:01:43:21.716 |
| Model status | OK |
| Load directory | /data/acis/LoadReviews/2025/MAY1925/ofls |
| Run time | Thu May 15 11:33:02 2025 by acisdude |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
No TMP_FEP1_MONG Upper Limit Violations
No TMP_FEP1_MONG Lower Limit Violations
FEP1_MONG Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where TMP_FEP1_MONG >= 25.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| tmp_fep1_mong | -5.30 | -4.16 | -3.03 | -1.04 | 0.96 | 2.28 | 3.99 |
| pitch | -7.134 | -0.235 | -0.004 | -0.000 | 0.004 | 0.185 | 7.675 |
| tscpos | -1 | -1 | -1 | 0 | 0 | 1 | 1 |
| roll | -1.759 | -0.079 | -0.004 | 0.000 | 0.004 | 0.070 | 1.977 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| TMP_FEP1_MONG | 1 | -5.3 | 2.00 |
| TMP_FEP1_MONG | 50 | -1.04 | 1.00 |
| TMP_FEP1_MONG | 99 | 3.99 | 2.00 |
| PITCH | 1 | -7.134 | 3.00 |
| PITCH | 99 | 7.675 | 3.00 |
TMP_FEP1_MONG
Note: TMP_FEP1_MONG residual histograms include only points where TMP_FEP1_MONG >= 25.0 C in blue and points where TMP_FEP1_MONG <= 20.0 C in red.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
