FEP1_MONG Temperatures Check
Summary
| Date start | 2025:318:21:50:00.016 |
| Date stop | 2025:327:21:06:00.016 |
| Model status | OK |
| Load directory | /data/acis/LoadReviews/2025/NOV1425/oflsa |
| Run time | Thu Nov 13 11:27:23 2025 by acisdude |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
No TMP_FEP1_MONG Upper Limit Violations
No TMP_FEP1_MONG Lower Limit Violations
FEP1_MONG Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where TMP_FEP1_MONG >= 25.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| tmp_fep1_mong | -7.00 | -5.61 | -3.74 | -1.02 | 0.79 | 1.95 | 3.23 |
| pitch | -12.895 | -1.519 | -0.004 | -0.000 | 0.004 | 1.276 | 13.626 |
| tscpos | -1 | -1 | -1 | 0 | 0 | 0 | 1 |
| roll | -2.360 | -0.261 | -0.007 | -0.000 | 0.007 | 0.232 | 2.622 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| TMP_FEP1_MONG | 1 | -7.0 | 2.00 |
| TMP_FEP1_MONG | 50 | -1.02 | 1.00 |
| TMP_FEP1_MONG | 99 | 3.23 | 2.00 |
| PITCH | 1 | -12.895 | 3.00 |
| PITCH | 99 | 13.626 | 3.00 |
TMP_FEP1_MONG
Note: TMP_FEP1_MONG residual histograms include only points where TMP_FEP1_MONG >= 25.0 C in blue and points where TMP_FEP1_MONG <= 20.0 C in red.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
