FEP1_MONG Temperatures Check
Summary
| Date start | 2026:291:23:49:06.416 |
| Date stop | 2026:298:16:38:00.016 |
| Model status | NOT OK |
| Load directory | /data/acis/LoadReviews/2026/OCT1926/oflsa |
| Run time | Thu Oct 15 08:42:49 2026 by acisdude |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
TMP_FEP1_MONG Upper Limit Violations
| Date start | Date stop | Duration (ks) | Max Temperature / Limit |
|---|---|---|---|
| 2026:295:22:44:03.616 | 2026:295:22:45:09.216 | 0.07 | 47.01 / 47.00 |
No TMP_FEP1_MONG Lower Limit Violations
FEP1_MONG Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where TMP_FEP1_MONG >= 25.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| tmp_fep1_mong | -4.55 | -3.17 | -1.70 | -0.09 | 1.68 | 2.78 | 4.23 |
| pitch | -14.295 | -1.824 | -0.004 | -0.000 | 0.004 | 1.743 | 14.241 |
| tscpos | -1 | -1 | -1 | 0 | 0 | 0 | 1 |
| roll | -2.584 | -0.304 | -0.011 | -0.000 | 0.011 | 0.269 | 2.868 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| TMP_FEP1_MONG | 1 | -4.55 | 2.00 |
| TMP_FEP1_MONG | 99 | 4.23 | 2.00 |
| PITCH | 1 | -14.295 | 3.00 |
| PITCH | 99 | 14.241 | 3.00 |
TMP_FEP1_MONG
Note: TMP_FEP1_MONG residual histograms include only points where TMP_FEP1_MONG >= 25.0 C in blue and points where TMP_FEP1_MONG <= 20.0 C in red.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
