ACISFP Temperatures Check
Summary
| Date start | 2025:103:21:55:07.116 |
| Date stop | 2025:111:00:41:00.016 |
| Model status | OK |
| Load directory | /data/acis/LoadReviews/2025/APR1425/ofls |
| Run time | Wed Apr 9 18:17:04 2025 by acisdude |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| Earth Solid Angles | earth_solid_angles.dat |
| States | states.dat |
No FPTEMP Upper Limit Violations
ACISFP Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where -120.0 C <= FPTEMP <= -100.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| fptemp | -1.72 | -1.24 | -0.64 | 0.43 | 1.46 | 2.33 | 4.03 |
| pitch | -5.577 | -0.354 | -0.004 | 0.000 | 0.004 | 0.471 | 5.700 |
| tscpos | -1 | -1 | -1 | 0 | 0 | 0 | 1 |
| roll | -1.486 | -0.145 | -0.008 | 0.000 | 0.009 | 0.169 | 1.282 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| FPTEMP | 99 | 4.03 | 2.00 |
| PITCH | 1 | -5.577 | 3.00 |
| PITCH | 99 | 5.7 | 3.00 |
FPTEMP
Note: FPTEMP residual histograms include only points where -120.0 C <= FPTEMP <= -100.0 C.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
Earth Solid Angle
ADDITIONAL PLOTS
Additional plots of FPTEMP vs TIME for different temperature ranges
