ACISFP Temperatures Check
Summary
| Date start | 2025:111:00:38:00.016 |
| Date stop | 2025:118:00:24:12.316 |
| Model status | NOT OK |
| Load directory | /data/acis/LoadReviews/2025/APR2125/ofls |
| Run time | Thu Apr 17 13:37:37 2025 by acisdude |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| Earth Solid Angles | earth_solid_angles.dat |
| States | states.dat |
FPTEMP Upper Limit Violations
| Date start | Date stop | Duration / Exposure (ks) | Max Temperature / Limit | Obsid |
|---|---|---|---|---|
| 2025:114:00:53:51.940 | 2025:114:01:01:50.816 | 0.48 / 17.50 | -110.66 / -111.00 | 30910 |
ACISFP Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where -120.0 C <= FPTEMP <= -100.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| fptemp | -2.31 | -1.42 | -0.62 | 0.28 | 1.46 | 2.20 | 3.67 |
| pitch | -5.703 | -0.505 | -0.004 | 0.000 | 0.004 | 0.585 | 5.567 |
| tscpos | -1 | -1 | -1 | 0 | 0 | 1 | 1 |
| roll | -1.486 | -0.108 | -0.008 | 0.000 | 0.009 | 0.163 | 1.368 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| FPTEMP | 1 | -2.31 | 2.00 |
| FPTEMP | 99 | 3.67 | 2.00 |
| PITCH | 1 | -5.703 | 3.00 |
| PITCH | 99 | 5.567 | 3.00 |
FPTEMP
Note: FPTEMP residual histograms include only points where -120.0 C <= FPTEMP <= -100.0 C.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
Earth Solid Angle
ADDITIONAL PLOTS
Additional plots of FPTEMP vs TIME for different temperature ranges
