ACISFP Temperatures Check
Summary
| Date start | 2025:195:01:13:43.816 |
| Date stop | 2025:202:00:04:37.716 |
| Model status | NOT OK |
| Load directory | /data/acis/LoadReviews/2025/JUL1425/ofls |
| Run time | Thu Jul 10 12:47:16 2025 by acisdude |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| Earth Solid Angles | earth_solid_angles.dat |
| States | states.dat |
FPTEMP Upper Limit Violations
| Date start | Date stop | Duration / Exposure (ks) | Max Temperature / Limit | Obsid |
|---|---|---|---|---|
| 2025:199:00:05:50.816 | 2025:199:00:07:14.947 | 0.08 / 21.00 | -110.96 / -111.00 | 28727 |
ACISFP Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where -120.0 C <= FPTEMP <= -100.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| fptemp | -3.05 | -2.50 | -1.76 | -0.02 | 1.57 | 2.57 | 3.10 |
| pitch | -8.651 | -0.264 | -0.004 | -0.000 | 0.004 | 0.366 | 10.451 |
| tscpos | -1 | -1 | -1 | 0 | 0 | 0 | 1 |
| roll | -1.732 | -0.118 | -0.007 | 0.000 | 0.007 | 0.144 | 1.840 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| FPTEMP | 1 | -3.05 | 2.00 |
| FPTEMP | 99 | 3.1 | 2.00 |
| PITCH | 1 | -8.651 | 3.00 |
| PITCH | 99 | 10.451 | 3.00 |
FPTEMP
Note: FPTEMP residual histograms include only points where -120.0 C <= FPTEMP <= -100.0 C.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
Earth Solid Angle
ADDITIONAL PLOTS
Additional plots of FPTEMP vs TIME for different temperature ranges
