ACISFP Temperatures Check
Summary
| Date start | 2026:179:17:06:00.016 |
| Date stop | 2026:186:23:50:27.716 |
| Model status | OK |
| Load directory | /data/acis/LoadReviews/2026/JUN2926/oflsa |
| Run time | Thu Jun 25 11:02:24 2026 by acisdude |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| Earth Solid Angles | earth_solid_angles.dat |
| States | states.dat |
No FPTEMP Upper Limit Violations
ACISFP Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where -120.0 C <= FPTEMP <= -100.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| fptemp | -1.76 | -1.21 | -0.62 | 0.35 | 1.56 | 2.25 | 3.01 |
| pitch | -11.254 | -0.365 | -0.004 | -0.000 | 0.004 | 0.370 | 8.611 |
| tscpos | -1 | -1 | -1 | 0 | 0 | 0 | 1 |
| roll | -1.976 | -0.089 | -0.007 | 0.000 | 0.008 | 0.089 | 1.794 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| FPTEMP | 99 | 3.01 | 2.00 |
| PITCH | 1 | -11.254 | 3.00 |
| PITCH | 99 | 8.611 | 3.00 |
FPTEMP
Note: FPTEMP residual histograms include only points where -120.0 C <= FPTEMP <= -100.0 C.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
Earth Solid Angle
ADDITIONAL PLOTS
Additional plots of FPTEMP vs TIME for different temperature ranges
