ACISFP Temperatures Check
Summary
| Date start | 2026:060:17:08:00.016 |
| Date stop | 2026:067:21:28:00.016 |
| Model status | OK |
| Load directory | /data/acis/LoadReviews/2026/MAR0226/oflsa |
| Run time | Wed Feb 25 19:54:42 2026 by acisdude |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| Earth Solid Angles | earth_solid_angles.dat |
| States | states.dat |
No FPTEMP Upper Limit Violations
ACISFP Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where -120.0 C <= FPTEMP <= -100.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| fptemp | -1.76 | -1.45 | -1.00 | -0.21 | 0.73 | 1.57 | 2.97 |
| pitch | -10.368 | -0.697 | -0.004 | -0.000 | 0.004 | 0.422 | 12.490 |
| tscpos | -1 | -1 | -1 | 0 | 0 | 0 | 1 |
| roll | -1.773 | -0.142 | -0.012 | -0.000 | 0.012 | 0.126 | 1.929 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| FPTEMP | 99 | 2.97 | 2.00 |
| PITCH | 1 | -10.368 | 3.00 |
| PITCH | 99 | 12.49 | 3.00 |
FPTEMP
Note: FPTEMP residual histograms include only points where -120.0 C <= FPTEMP <= -100.0 C.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
Earth Solid Angle
ADDITIONAL PLOTS
Additional plots of FPTEMP vs TIME for different temperature ranges
