PSMCBT Temperatures Check
Summary
| Date start | 2023:114:02:25:59.216 |
| Date stop | 2023:120:21:34:02.416 |
| Model status | OK |
| Load directory | /data/acis/LoadReviews/2023/APR2423/oflsb |
| Run time | Thu Oct 8 16:01:32 2026 by jsteiner |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
No 1PDEABT Upper Limit Violations
PSMCBT Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where 1PDEABT >= 22.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| 1pdeabt | -3.64 | -2.61 | -1.78 | -0.12 | 1.21 | 1.74 | 2.23 |
| pitch | -9.626 | -0.338 | -0.003 | -0.000 | 0.003 | 0.202 | 10.262 |
| tscpos | -1 | -1 | -1 | 0 | 0 | 1 | 1 |
| roll | -1.414 | -0.065 | -0.004 | -0.000 | 0.005 | 0.132 | 1.682 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| 1PDEABT | 1 | -3.64 | 2.50 |
| PITCH | 1 | -9.626 | 3.00 |
| PITCH | 99 | 10.262 | 3.00 |
1PDEABT
Note: 1PDEABT residual histograms include only points where 1PDEABT >= 22.0 C in blue and points where 1PDEABT >= 32.0 C in red.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
