PSMCBT Temperatures Check
Summary
| Date start | 2024:231:22:21:14.416 |
| Date stop | 2024:239:02:21:00.016 |
| Model status | NOT OK |
| Load directory | /data/acis/LoadReviews/2024/AUG1924/oflsa |
| Run time | Thu Oct 8 16:02:30 2026 by jsteiner |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
1PDEABT Upper Limit Violations
| Date start | Date stop | Duration (ks) | Max Temperature / Limit |
|---|---|---|---|
| 2024:237:02:00:38.816 | 2024:237:02:17:02.816 | 0.98 | 43.75 / 43.50 |
PSMCBT Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where 1PDEABT >= 22.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| 1pdeabt | -3.54 | -2.19 | -1.20 | 0.09 | 1.60 | 2.47 | 3.30 |
| pitch | -6.765 | -0.077 | -0.004 | 0.000 | 0.004 | 0.071 | 7.525 |
| tscpos | -1 | -1 | -1 | -1 | 0 | 0 | 0 |
| roll | -1.546 | -0.034 | -0.005 | 0.000 | 0.005 | 0.037 | 1.537 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| 1PDEABT | 1 | -3.54 | 2.50 |
| PITCH | 1 | -6.765 | 3.00 |
| PITCH | 99 | 7.525 | 3.00 |
1PDEABT
Note: 1PDEABT residual histograms include only points where 1PDEABT >= 22.0 C in blue and points where 1PDEABT >= 32.0 C in red.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
