PSMCBT Temperatures Check
Summary
| Date start | 2023:239:23:08:59.616 |
| Date stop | 2023:246:15:08:50.816 |
| Model status | OK |
| Load directory | /data/acis/LoadReviews/2023/AUG2823/oflsa |
| Run time | Thu Oct 8 16:02:58 2026 by jsteiner |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
No 1PDEABT Upper Limit Violations
PSMCBT Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where 1PDEABT >= 22.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| 1pdeabt | -3.54 | -2.71 | -1.88 | -0.33 | 1.25 | 2.08 | 2.73 |
| pitch | -8.993 | -0.121 | -0.004 | 0.000 | 0.004 | 0.176 | 7.397 |
| tscpos | -1 | -1 | -1 | 0 | 0 | 0 | 1 |
| roll | -1.653 | -0.068 | -0.002 | 0.000 | 0.003 | 0.078 | 1.631 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| 1PDEABT | 1 | -3.54 | 2.50 |
| PITCH | 1 | -8.993 | 3.00 |
| PITCH | 99 | 7.397 | 3.00 |
1PDEABT
Note: 1PDEABT residual histograms include only points where 1PDEABT >= 22.0 C in blue and points where 1PDEABT >= 32.0 C in red.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
