PSMCBT Temperatures Check
Summary
| Date start | 2023:036:20:01:06.316 |
| Date stop | 2023:044:02:19:10.716 |
| Model status | OK |
| Load directory | /data/acis/LoadReviews/2023/FEB0623/oflsa |
| Run time | Thu Oct 8 16:04:07 2026 by jsteiner |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
No 1PDEABT Upper Limit Violations
PSMCBT Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where 1PDEABT >= 22.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| 1pdeabt | -3.82 | -2.84 | -2.09 | -0.55 | 0.77 | 1.34 | 1.83 |
| pitch | -11.804 | -0.710 | -0.004 | -0.000 | 0.004 | 0.642 | 10.918 |
| tscpos | -1 | -1 | -1 | 0 | 0 | 1 | 1 |
| roll | -2.012 | -0.158 | -0.004 | -0.000 | 0.004 | 0.155 | 2.311 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| 1PDEABT | 1 | -3.82 | 2.50 |
| PITCH | 1 | -11.804 | 3.00 |
| PITCH | 99 | 10.918 | 3.00 |
1PDEABT
Note: 1PDEABT residual histograms include only points where 1PDEABT >= 22.0 C in blue and points where 1PDEABT >= 32.0 C in red.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
