PSMCBT Temperatures Check
Summary
| Date start | 2025:020:00:53:32.716 |
| Date stop | 2025:026:10:03:00.016 |
| Model status | OK |
| Load directory | /data/acis/LoadReviews/2025/JAN2025/oflsa |
| Run time | Thu Oct 8 16:06:25 2026 by jsteiner |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
No 1PDEABT Upper Limit Violations
PSMCBT Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where 1PDEABT >= 22.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| 1pdeabt | -2.47 | -1.70 | -0.83 | 0.60 | 1.86 | 2.45 | 2.94 |
| pitch | -10.007 | -1.037 | -0.004 | -0.000 | 0.004 | 0.939 | 10.306 |
| tscpos | -1 | -1 | -1 | 0 | 0 | 1 | 1 |
| roll | -1.936 | -0.183 | -0.006 | 0.000 | 0.007 | 0.241 | 1.973 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| PITCH | 1 | -10.007 | 3.00 |
| PITCH | 99 | 10.306 | 3.00 |
1PDEABT
Note: 1PDEABT residual histograms include only points where 1PDEABT >= 22.0 C in blue and points where 1PDEABT >= 32.0 C in red.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
