PSMCBT Temperatures Check
Summary
| Date start | 2026:025:19:05:18.516 |
| Date stop | 2026:032:23:33:17.516 |
| Model status | OK |
| Load directory | /data/acis/LoadReviews/2026/JAN2626/oflsa |
| Run time | Thu Oct 8 16:06:25 2026 by jsteiner |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
No 1PDEABT Upper Limit Violations
PSMCBT Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where 1PDEABT >= 22.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| 1pdeabt | -2.86 | -1.43 | -0.65 | 0.74 | 1.99 | 2.67 | 3.33 |
| pitch | -11.845 | -0.587 | -0.004 | 0.000 | 0.004 | 0.706 | 11.217 |
| tscpos | -1 | -1 | -1 | 0 | 0 | 0 | 1 |
| roll | -2.121 | -0.234 | -0.009 | -0.000 | 0.006 | 0.172 | 1.759 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| 1PDEABT | 1 | -2.86 | 2.50 |
| PITCH | 1 | -11.845 | 3.00 |
| PITCH | 99 | 11.217 | 3.00 |
1PDEABT
Note: 1PDEABT residual histograms include only points where 1PDEABT >= 22.0 C in blue and points where 1PDEABT >= 32.0 C in red.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
