PSMCBT Temperatures Check
Summary
| Date start | 2026:193:22:54:34.016 |
| Date stop | 2026:200:20:48:00.016 |
| Model status | OK |
| Load directory | /data/acis/LoadReviews/2026/JUL1326/oflsa |
| Run time | Thu Oct 8 16:07:23 2026 by jsteiner |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
No 1PDEABT Upper Limit Violations
PSMCBT Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where 1PDEABT >= 22.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| 1pdeabt | -3.30 | -2.11 | -1.41 | -0.01 | 1.49 | 2.21 | 2.90 |
| pitch | -10.563 | -0.398 | -0.004 | -0.000 | 0.004 | 0.123 | 10.807 |
| tscpos | -1 | -1 | -1 | 0 | 0 | 1 | 1 |
| roll | -1.788 | -0.074 | -0.006 | 0.000 | 0.006 | 0.072 | 1.559 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| 1PDEABT | 1 | -3.3 | 2.50 |
| PITCH | 1 | -10.563 | 3.00 |
| PITCH | 99 | 10.807 | 3.00 |
1PDEABT
Note: 1PDEABT residual histograms include only points where 1PDEABT >= 22.0 C in blue and points where 1PDEABT >= 32.0 C in red.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
