PSMCBT Temperatures Check
Summary
| Date start | 2023:156:00:06:19.516 |
| Date stop | 2023:163:03:38:37.716 |
| Model status | OK |
| Load directory | /data/acis/LoadReviews/2023/JUN0523/oflsa |
| Run time | Thu Oct 8 16:08:22 2026 by jsteiner |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
No 1PDEABT Upper Limit Violations
PSMCBT Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where 1PDEABT >= 22.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| 1pdeabt | -3.12 | -2.28 | -1.34 | 0.43 | 1.61 | 2.30 | 4.40 |
| pitch | -7.955 | -0.334 | -0.003 | 0.000 | 0.003 | 0.331 | 8.499 |
| tscpos | -1 | -1 | -1 | -1 | 0 | 1 | 1 |
| roll | -1.285 | -0.081 | -0.003 | 0.000 | 0.004 | 0.127 | 1.605 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| 1PDEABT | 1 | -3.12 | 2.50 |
| PITCH | 1 | -7.955 | 3.00 |
| PITCH | 99 | 8.499 | 3.00 |
1PDEABT
Note: 1PDEABT residual histograms include only points where 1PDEABT >= 22.0 C in blue and points where 1PDEABT >= 32.0 C in red.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
