PSMCBT Temperatures Check
Summary
| Date start | 2023:064:17:38:00.016 |
| Date stop | 2023:071:23:56:01.616 |
| Model status | OK |
| Load directory | /data/acis/LoadReviews/2023/MAR0623/oflsa |
| Run time | Thu Oct 8 16:09:19 2026 by jsteiner |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
No 1PDEABT Upper Limit Violations
PSMCBT Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where 1PDEABT >= 22.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| 1pdeabt | -4.41 | -3.00 | -1.90 | -0.47 | 0.56 | 1.28 | 2.05 |
| pitch | -59.650 | -52.499 | -3.099 | -0.000 | 0.004 | 72.083 | 80.614 |
| tscpos | -1 | -1 | -1 | 0 | 0 | 0 | 0 |
| roll | -173.602 | -169.083 | -0.016 | -0.000 | 0.008 | 67.692 | 75.335 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| 1PDEABT | 1 | -4.41 | 2.50 |
| PITCH | 1 | -59.65 | 3.00 |
| PITCH | 99 | 80.614 | 3.00 |
1PDEABT
Note: 1PDEABT residual histograms include only points where 1PDEABT >= 22.0 C in blue and points where 1PDEABT >= 32.0 C in red.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
