PSMCBT Temperatures Check
Summary
| Date start | 2025:068:17:45:00.016 |
| Date stop | 2025:075:23:56:28.016 |
| Model status | OK |
| Load directory | /data/acis/LoadReviews/2025/MAR1025/oflsb |
| Run time | Thu Oct 8 16:09:55 2026 by jsteiner |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
No 1PDEABT Upper Limit Violations
PSMCBT Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where 1PDEABT >= 22.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| 1pdeabt | -2.97 | -2.34 | -1.63 | -0.32 | 1.24 | 1.94 | 2.65 |
| pitch | -11.172 | -1.239 | -0.004 | -0.000 | 0.004 | 1.049 | 9.919 |
| tscpos | -1 | -1 | -1 | 0 | 0 | 1 | 1 |
| roll | -2.400 | -0.256 | -0.010 | -0.000 | 0.009 | 0.302 | 2.882 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| 1PDEABT | 1 | -2.97 | 2.50 |
| PITCH | 1 | -11.172 | 3.00 |
| PITCH | 99 | 9.919 | 3.00 |
1PDEABT
Note: 1PDEABT residual histograms include only points where 1PDEABT >= 22.0 C in blue and points where 1PDEABT >= 32.0 C in red.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
