PSMCBT Temperatures Check
Summary
| Date start | 2023:071:23:53:01.616 |
| Date stop | 2023:078:19:55:02.116 |
| Model status | OK |
| Load directory | /data/acis/LoadReviews/2023/MAR1323/oflsa |
| Run time | Thu Oct 8 16:09:55 2026 by jsteiner |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
No 1PDEABT Upper Limit Violations
PSMCBT Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where 1PDEABT >= 22.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| 1pdeabt | -2.94 | -2.05 | -1.27 | 0.04 | 1.33 | 2.22 | 3.06 |
| pitch | -59.650 | -13.307 | -0.004 | -0.000 | 0.003 | 72.083 | 80.614 |
| tscpos | -1 | -1 | -1 | 0 | 0 | 0 | 0 |
| roll | -169.771 | -91.339 | -0.008 | -0.000 | 0.006 | 3.004 | 68.611 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| 1PDEABT | 1 | -2.94 | 2.50 |
| PITCH | 1 | -59.65 | 3.00 |
| PITCH | 99 | 80.614 | 3.00 |
1PDEABT
Note: 1PDEABT residual histograms include only points where 1PDEABT >= 22.0 C in blue and points where 1PDEABT >= 32.0 C in red.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
