PSMCBT Temperatures Check
Summary
| Date start | 2023:141:09:37:28.016 |
| Date stop | 2023:148:20:14:09.416 |
| Model status | OK |
| Load directory | /data/acis/LoadReviews/2023/MAY2223/oflsa |
| Run time | Thu Oct 8 16:12:02 2026 by jsteiner |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
No 1PDEABT Upper Limit Violations
PSMCBT Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where 1PDEABT >= 22.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| 1pdeabt | -2.82 | -1.69 | -0.80 | 0.53 | 1.73 | 2.38 | 4.90 |
| pitch | -8.760 | -0.383 | -0.003 | 0.000 | 0.003 | 0.300 | 9.001 |
| tscpos | -1 | -1 | -1 | 0 | 0 | 1 | 1 |
| roll | -1.337 | -0.081 | -0.004 | -0.000 | 0.004 | 0.096 | 1.644 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| 1PDEABT | 1 | -2.82 | 2.50 |
| PITCH | 1 | -8.76 | 3.00 |
| PITCH | 99 | 9.001 | 3.00 |
1PDEABT
Note: 1PDEABT residual histograms include only points where 1PDEABT >= 22.0 C in blue and points where 1PDEABT >= 32.0 C in red.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
