PSMCBT Temperatures Check
Summary
| Date start | 2024:280:22:39:12.216 |
| Date stop | 2024:287:23:24:36.316 |
| Model status | OK |
| Load directory | /data/acis/LoadReviews/2024/OCT0724/oflsa |
| Run time | Thu Oct 8 16:13:31 2026 by jsteiner |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
No 1PDEABT Upper Limit Violations
PSMCBT Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where 1PDEABT >= 22.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| 1pdeabt | -3.57 | -2.70 | -1.77 | -0.50 | 1.22 | 1.97 | 2.99 |
| pitch | -10.088 | -0.483 | -0.004 | -0.000 | 0.004 | 0.563 | 9.259 |
| tscpos | -1 | -1 | -1 | -1 | 0 | 0 | 1 |
| roll | -1.916 | -0.132 | -0.008 | 0.000 | 0.007 | 0.133 | 2.201 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| 1PDEABT | 1 | -3.57 | 2.50 |
| PITCH | 1 | -10.088 | 3.00 |
| PITCH | 99 | 9.259 | 3.00 |
1PDEABT
Note: 1PDEABT residual histograms include only points where 1PDEABT >= 22.0 C in blue and points where 1PDEABT >= 32.0 C in red.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
