PSMCBT Temperatures Check
Summary
| Date start | 2024:287:00:54:58.016 |
| Date stop | 2024:295:01:27:44.616 |
| Model status | OK |
| Load directory | /data/acis/LoadReviews/2024/OCT1324/oflsb |
| Run time | Thu Oct 8 16:13:31 2026 by jsteiner |
| Run log | run.dat |
| Temperatures | temperatures.dat |
| States | states.dat |
No 1PDEABT Upper Limit Violations
PSMCBT Model Validation
MSID quantiles
Note: Quantiles are calculated using only points where 1PDEABT >= 22.0 C.
| MSID | 1% | 5% | 16% | 50% | 84% | 95% | 99% |
|---|---|---|---|---|---|---|---|
| 1pdeabt | -3.36 | -2.64 | -1.76 | -0.46 | 1.28 | 2.01 | 3.06 |
| pitch | -9.356 | -0.566 | -0.004 | -0.000 | 0.004 | 0.563 | 9.243 |
| tscpos | -1 | -1 | -1 | 0 | 0 | 0 | 1 |
| roll | -2.031 | -0.110 | -0.008 | 0.000 | 0.009 | 0.153 | 2.592 |
Validation Violations
| MSID | Quantile | Value | Limit |
|---|---|---|---|
| 1PDEABT | 1 | -3.36 | 2.50 |
| PITCH | 1 | -9.356 | 3.00 |
| PITCH | 99 | 9.243 | 3.00 |
1PDEABT
Note: 1PDEABT residual histograms include only points where 1PDEABT >= 22.0 C in blue and points where 1PDEABT >= 32.0 C in red.
PITCH
TSCPOS
ROLL
ACIS CCD/FEP Count
